Inter-lock Armoring Machine

I. Introduction

Inter-lock Armoring Machine is mainly used for inter-lock armoring round or flat cables and submersible pump cables.

II.Equipment major components

Equipment Major Component

III. Techinical parameters

Model	SH-IA50	SH-IA100	SH-IA130
Armored cable outer diameter	Φ8～Φ100mm	Φ8～Φ100mm	Φ8～Φ130mm
Max armoring rotation speed	1000 r/min	710 r/min	710 r/min
Steel tape armoring pitch	6.3～8.5mm	6.3～16.9mm	6.3～16.9mm
Max. traction force	800kg	1250kg	1250kg
Max. linear speed	11.6m/min	11.6m/min	11.6m/min
Armoring material	Aluminium,aluminium alloy,copper,Zinc-plated steel,stainless steel
Armoring type	S	S	S
Pay off reel	PN1000～PN1600	PN1250～PN2000	PN1250～PN2000
Take-up reel	PN1250～PN2000	PN1250～PN2500	PN1250～PN2500
Main motor for armoring	18.5kW(AC frequency motor)	30kW(AC frequency motor)	30kW(AC frequency motor)
Coils conveying motor	7.5kW(AC servo motor)	7.5kW(AC servo motor)	7.5kW(AC servo motor)
Traction motor	1.5kW(AC servo motor)	1.5kW(AC servo motor)	1.5kW(AC servo motor)
