Double-roller Reversible Copper Strips Cold Rolling Line
  • FEATURES
  • DIMENSIONAL SHEET
  • GALLERY & MULTIMEDIA

  • I. Introduction

    Double-roller Reversible Cold Rolling Machine for Copper Strips is used for the multiple rolling of the copper bus bars of 4-12mm in thickness into thinner copper strips.


    II. Equipment major components












    III. Main technical parameters

    Model

    SH-CRS400

    SH-CRS700

    Raw material

    Copper

    Inlet thickness

    4～12mm

    4～12mm

    Outlet thickness

    1.0-10mm

    1.0-10mm

    Inlet width

    100～300mm

    400～600mm

    Outlet width

    60～300mm

    350～600mm

    Max. Rolling pressure

    2000 KN

    4000 KN

    Max. Rolling speed

    60 m/min

    60 m/min

    Max. Take-up speed

    60 m/min

    60 m/min

    Take-up tension

    7～70 KN

    7～70 KN

    Hydraulic transmission pressure

    10MPa

    10MPa

    Main rolling machine motor power

    315KW

    N=550KW

    Take-up motor power

    110kW

    N=250kW




    Related suggestion：Copper Strips
